Models - Single shaft shredders ISVE
Single-shaft shredders: Model MS 22-60
The MS 22-60 single-shaft shredder is particularly suitable to shred high-consisting wastes. A hydraulic control unit allows driving the pusher drawer. Thus, the product to be grinded is pushed towards a tools-holder rotor causing its crushing. Thanks to a screen it is possible to select the final dimension of the shredder material. Main features: Power installed on the rotor: 18,5 kW (25 HP) Power of the hydraulic control unit: 2,2 kW (HP 3) Drive: by belts Number of rotors: 1 Rotor diameter: 220 mm Rotor length: 600 mm Number of reversible tools: 27 N° of usable tools sides: 4 Average number of rotor revolutions per min: 85 Weight: 1.800 kg Production: 200-400 kg/h Safety devices: emergency stop, drawer reversal system.
Single-shaft shredders: Model MS 40-80 IT (2022 VERSION)
The MS 40-80 IT single-shaft shredder is particularly suitable to shred high quantities of industrial wastes. The heavy structure makes the machine suitable to realize a heavy use. A hydraulic control unit allows driving the pusher drawer. Thus, the product to be grinded is pushed towards a tools-holder rotor causing its crushing. Thanks to a screen it is possible to select the final dimension of the shredder material. Main features: Power installed on the rotor: 37 kW (50 HP) Power of the hydraulic control unit: 4 kW (HP 5,4) Drive: by belts Number of rotors: 1 Rotor diameter: 400 mm Rotor length: 700 mm Pusher stroke: 800 mm Number of reversible tools: 44 N° of usable tools sides: 4 Upper
Single-shaft shredders: Model MS 40-100 IT (2022 VERSION)
The MS 40-100 IT singe-shaft shredder is particularly suitable to shred high quantities of industrial wastes. The heavy structure makes the machine suitable to realize a heavy use. A hydraulic control unit allows driving the pusher drawer. Thus, the product to be grinded is pushed towards a tools-holder rotor causing its crushing. Thanks to a screen it is possible to select the final dimension of the shredder material. Main features: Power installed on the rotor: 45 kW (60 HP) Power of the hydraulic control unit: 4 kW (HP 5,4) Drive: by belts Number of rotors: 1 Rotor diameter: 400 mm Rotor length: 900 mm Pusher stroke: 800 mm Number of reversible tools: 52 N° of usable tools sides: 4 Upper
Single-shaft shredders: Model MS 40-120 IT (2022 VERSION)
The MR 40-120 singe-shaft equipped shredder is particularly suitable to shred high quantities of industrial wastes. The MS 40-120 IT singe-shaft shredder is particularly suitable to shred high quantities of industrial wastes. The heavy structure makes the machine suitable to realize a heavy use. A hydraulic control unit allows driving the pusher drawer. Thus, the product to be grinded is pushed towards a tools-holder rotor causing its crushing. Thanks to a screen it is possible to select the final dimension of the shredder material. Main features: Power installed on the rotor: 55 kW (75 HP) optional: 75 kW (100 HP) Power of the hydraulic control unit: 5,5 kW (HP 7,5) Drive: by belts Number of rotors: 1 Rotor diameter
Single-shaft shredders: Model MS 40-140 IT (2022 VERSION)
The MS 40-140 IT singe-shaft equipped shredder is particularly suitable to shred high quantities of industrial wastes. The heavy structure makes the machine suitable to realize a heavy use. A hydraulic control unit allows driving the pusher drawer. Thus, the product to be grinded is pushed towards a tools-holder rotor causing its crushing. Thanks to a screen it is possible to select the final dimension of the shredder material. Main features: Power installed on the rotor: 75 kW (100 HP) optional: 90 kW (120 HP) Power of the hydraulic control unit: 5,5 kW (HP 7,5) Drive: by belts Number of rotors: 1 Rotor diameter: 400 mm Rotor length: 1.300 mm Pusher stroke: 800 mm Number of reversible tools: 80 N°
Single-shaft shredders: Model MS 48-200 IT (2022 VERSION)
The MS 48-200 IT single-shaft shredder is particularly suitable to shred high quantities of industrial wastes. The heavy structure makes the machine suitable to realize an heavy use. A hydraulic control unit allows driving the pusher drawer. Thus, the product to be grinded is pushed towards a tools-holder rotor causing its crushing. Thanks to a screen it is possible to select the final dimension of the shredder material. Main features: Power installed on the rotor: 75 + 75 kW optional: 90+90 kW Power of the hydraulic control unit: 11 kW (15 HP) Drive: by belts (no. 2 hydraulic joints on the motor shaft) Number of rotors: 1 Rotor diameter: 480 mm Rotor length: 2.000 mm Pusher stroke: 1.000 mm Number
